MSI MAG VAMPIRIC 100R Atx Mid Tower
CONQUER THE BATTLEFIELD

The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.

MESH CERTIFIED MAKES IT WORK

The MAG VAMPIRIC 100 Series stands at the equilibrium where function seamlessly meets design. The front mesh panel allows air to flow into the case easily without obstruction, providing the best system cooling performance. The supreme cooling performance is further highlighted by the front panel light, showcasing VAMPIRIC 100 Series’ good looks and superior functionality.

DESIGNED FOR PERFORMANCE

The front mesh panel has been built to effectively let in air for maximum ventilation while stunning onlookers with its striking design.

INSTA-LIGHT LOOP BUTTON

Quickly control the fan color and lighting effects with Insta-Light Loop at the touch of a button. Click through the profiles at ease and choose a favorite.

TEMPERED GLASS WINDOW

The MAG VAMPIRIC 100 Series reveals your arsenal with a tempered glass side panel. Arm the system with MSI’s liquid cooler, motherboard, and graphics card for the ultimate display of power and performance.

MAGNETIC DUST FILTER

A magnetic filter sits on the top vents keeping dust from falling inside while being easily removed for cleaning.

OPTIMIZED AIRFLOW DESIGN

The MAG VAMPIRIC 100 Series has been engineered to focus air flow across the system for incredible cooling performance.

Up to 6 fans can be installed.

PRODUCT SPEC
Product Name

MAG VAMPIRIC 100R

Support MB Form Factor

ATX / M-ATX / Mini-ITX

Dimension (W) x (D) x (H)

205 x 390 x 457 mm / 8.07 x 15.35 x 17.99 inches

I/O Ports

1 x USB 3.2 Gen 1 Type A / 2 x USB 2.0 / HD Audio / Mic

Driver Bays

2 x 2.5″ + 2 x 3.5″ (1 x compatible with 2.5″)

VGA Card Support

Max 300 mm / 11.81 inch

CPU Cooler Support

Max 160 mm / 6.3 inch

Power Supply

Standard ATX, max to 270 mm( without 3.5″ HDD tray installed )

Cooling Layout

Front Max: 3 x 120 mm or 2 x 140 mm(1 x 120 mm Fan included)
Top: Max: 2 x 120 mm
Rear: 1 x 120 mm(1 x 120 mm ARGB Fan included)

Radiator Layout

Front: up to 240 mm / Rear: up to 120 mm
