Asus Rog Thor 850W Platinum Power Supply Unit
Inside and out, our first PSU is packed with innovative ideas. Externally, Aura Sync RGB illumination and an integrated OLED information panel enable unique customization and monitoring options for your ROG gaming rig. Under the hood, high-quality capacitors, a 135mm Wing-blade fan, and large heatsinks allow the ROG Thor 850W to achieve LAMBDA A+ and 80 PLUS® Platinum certifications, making it ideal for PC enthusiasts who demand performance perfection.
ASUS Aura Sync
Outshine The Competition
ASUS Aura Sync is the illumination ecosystem that lets you synchronize lighting effects across your gaming rig, components, and peripherals. The ROG Thor 850W Platinum has addressable Aura RGB LEDs built in and ready for you to create your custom look.
– Two included connector cables allows you to connect onto your ASUS Motherboard’s addressable RGB header or create a daisy chain with ROG Addressable LED Strips.
– Without using the included connector cables, the default effect and color will be static red.
OLED POWER DISPLAY
The ROG Thor 850W Platinum is the first PC PSU in the world to feature an integrated OLED panel, offering a real-time display of power draw. Now you can see at a glance how much juice your rig is using.
We’ve equipped the ROG Thor 850W Platinum with a 135mm patented Wing-blade fan to maximize component lifespan. IP5X dust-resistance keeps it spinning freely and 0dB technology utilizes thermal sensors to allow the fan to switch off completely at lower wattages — enabling totally silent operation.
The integrated ROG heatsinks have 2x more volume than traditional designs, resulting in 20% lower temperatures inside the ROG Thor 850W Platinum. This extends the lifespan of components and allows 0dB operation for a longer duration than standard designs. The heatsinks are so effective that fan noise never exceeds 20dB, allowing ROG Thor to achieve LAMBDA A+ certification.
80 PLUS PLATINUM CERTIFICATION
The ROG Thor 850W Platinum utilizes top-end Japanese capacitors to ensure efficient operation. This has earned an 80 PLUS Platinum certification, which guarantees 89% efficiency at 100% load and 92% at 50% load. The increased efficiency produces less heat, reducing fan noise and increasing reliability.
We know you’ll want to get building right away, so we’ve included high-quality sleeved and standard cables. The sleeved cables include one 24-pin, two 6+2-pin PCI-e cables and two 8-pin CPU cables. We’ve also included an RGB connector that plugs into the addressable RGB header on your ASUS motherboard.
*For something punchier than pure black, we’ve teamed up with CableMod to offer a 20% discount. Customize cable colors, length, and materials to match your rig.
Intel Specification: ATX12V
Dimensions: 6.3 ” x 5.9 ” x 3.38 ” Inch, 16 x 15 x8.6 Centimeter
Efficiency: 80Plus Platinum
Protection Features: OPP/OVP/SCP/OCP/OTP
AC Input Range: 100-240Vac
DC Output Voltage: +3.3V +5V +12V -12V +5Vsb
Maximum Load: 20A 20A 71A 0.3A 3A
Total Output: 852W
